12V 60w Transformer Power Supply Driver Led Light Waterproof Ip67
60W DC Waterproof LED Transformer Power Supply Driver
Features :
IP67 design for indoor or outdoor installations
Protections: Short circuit / Overload/Over temperature
Cooling by free air convection
100% full load burn-in test
Suitable for LED lighting
Products through CE, RoHS Certification
1 years warrantyIP67
| SPECIFICATION |
| MODEL | 05V60W | 12V60W | 24V60W | 36V60W |
|
OUTPUT | DC VOLTAGE | 5V | 12V | 24V | 36V |
| RATED CURRENT | 12A | 5A | 2.5A | 1.67A |
| CURRENT RANGE | 0~12A | 0~5A | 0~2.5A | |
| RATED POWER | 60W | 60W | 60W | 60W |
| NOTE.2 RIPPLE & NOISE (max.) | 150mV | 150mV | 150mV | 150mV |
| NOTE.3 VOLTAGE TOLERANCE | ±10% | ±4% | ±2% | ±2% |
| SETUP, RISE TIME | 80ms/220VAC |
| HOLD UP TIME (Typ.) | 60ms/220VAC |
|
INPUT | VOLTAGE RANGE | 170 ~ 250VAC |
| FREQUENCY RANGE | 50 ~ 60Hz |
| POWER FACTOR (Typ.) | PF>0.6/220VAC |
| EFFICIENCY (Typ.) | 77% | 80% | 81% | 82% |
| AC CURRENT (Typ.) | 0.57A/220VAC |
| INRUSH CURRENT (Typ.) | COLD START 40A/220VAC |
|
PROTECTION | Short circuit | Protection type : recovers automatically after fault condition is removed |
| Overload | overload protected @ 145-160% above peak rating |
| Over temperature | Protection type : Shut down o/p voltage, re-power on to recover |
|
ENVIRONMENT | WORKING TEMP. | -30 ~ +50℃ (Refer to output load derating curve) |
| WORKING HUMIDITY | 20 ~ 99% RH non-condensing(Waterproof) |
| STORAGE TEMP., HUMID IT Y | -40 ~ +80℃ , 10 ~ 99% RH |
|
SAFETY & EMC | SAFETY STANDARDS | CE Mark (LVD) , IP67 |
| WITHSTAND VOLTAGE | I/P-O/P:1.5KVAC I/P-GND:1.5KVAC |
| EMC Test Standards | EN55015:2006 ; EN61547:1995+A1:2000 ; EN61000-3-2:2006 ; EN61000-3-3:1995+A2:2005 ; EN61347-1:2001 ; EN61347-2-13:2006 |
|
NOTE | 1. All parameters NOT specially mentioned are measured at 220VAC input, rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 1 0 uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation. |
| DIMENSION | 187×69×43(mm) (L×W×H) |
| CARTO N QUANTI TY | 20PCS/Carton |
| CARTON SIZE | 450×315×200(mm) |
| WEIGHT | 900g/PCS |
